STABILISERS

 PUMP 202
Cutting edge pumping performance to complement the APF front foil range.
The Pump 202 is designed specifically to complement the Armstrong Pump Foil (APF) front foil range. This stabiliser redefines pump foiling potential with its ultra-low stall speeds, incredible stability and high efficiency to take you further with less effort than ever.
Specifications:
Span: 397mm
Area: 202cm2
Aspect Ratio: 7.8
_____________________________________________________

S1 300
Redefining how we learn to foil.
Redefining how we learn to foil, the Step 1 (S1) foil range delivers remarkable stability, ultra low flying speed and an instantly intuitive feel to make the first step into foiling as accessible and forgiving as possible.

Pitch, roll and yaw stability are critical to success when building foiling skills. The S1 design achieves a near autopilot-like level of predictability thanks to a combination of leading and trailing edge sweep, chord length and foil section geometry. The result is an ultra easy platform for first time flyers to learn any foiling discipline.

The S1 foils fly at a remarkably low speed with a high degree of controllability so that riders can practise manoeuvres with less risk and a lower learning curve. When overpowered, the foil reduces breaching with a tendency to fly itself back down when approaching the surface. Because these foils handle speed and ventilation so well, riders can enjoy an exceptionally broad usable speed range in each size. Downturned wingtips provide an extra element of safety.
Details
An ultra easy platform for first time flyers to learn any foiling discipline. Excellent low speed lift, stability and recovery from ventilation.
Leading and trailing edge sweep for stability and a narrower span to minimise breaching.
Downturned wing tips increase rider safety and improve the efficiency of water flow.
Proprietary Armstrong A+ System foil connection design offers industry-leading stiffness, durability and modularity.
The S1 300 stabiliser was designed alongside the S1 foils to provide riders with the best learning platform possible.
Tech Specs
Span 410mm, AR 5.7
______________________________________________________

Glide 220
Glide with effortless pumping.
The Glide 220 is our stabiliser of choice when seeking the greatest glide and pump over long distances. It caters to intermediate through advanced riders pursuing lightwind winging, downwinding and flatwater pumping.
Recommendations
WING: Rider weight 60kg+ (132lbs+), Intermediate/Advanced
PRONE/SUP SURF: Rider weight 60kg+ (132lbs+), Intermediate/Advanced
DOWNWIND: Rider weight 60kg+ (132lbs+), Intermediate/Advanced
WAKE: Rider weight 60kg+ (132lbs+), Intermediate/Advanced
KITE: Rider weight 60kg+ (132lbs+), Intermediate/Advanced
Specifications:
Area: 220cm2
Span: 462mm
Aspect Ratio: 9.7
______________________________________________________

Seed 180
Highly efficient.
Designed as the evolution of the HA195 stabiliser, the 180 Speed offers greater efficiency and top end of intermediate through advanced wing, surf and downwind foilers. Its high modulus carbon construction is extra stiff for instant pumping and carving response.
Recommendations:
WING: Rider weight 50kg+ (110lbs+), Intermediate/Advanced
PRONE/SUP SURF: Rider weight 50kg+ (110lbs+), Intermediate/Advanced
DOWNWIND: Rider weight 50kg+ (110lbs+), Advanced
WAKE: Rider weight 50kg+ (110lbs+), Advanced
KITE: Rider weight 50kg+ (110lbs+), Intermediate/Advanced
Specifications:
Area: 180cm2
Span: 400mm
Aspect Ratio: 9
______________________________________________________

Dart 140
Lightning fast response with top end speed.
The Dart 140 is our smallest stabiliser and offers all the performance characteristics you'd expect from such a small surface area. Lightning fast response with minimal drag for high speeds, this is the tail of choice for advanced to expert wing, surf, tow and kite foilers in powered conditions.
Recommendations
WING: Rider weight 40kg+ (88lbs+), Advanced/Expert
PRONE/SUP SURF: Rider weight 40kg+ (88lbs+), Advanced/Expert
WAKE: Rider weight 40kg+ (88lbs+), Advanced/Expert
KITE: Rider weight 40kg+ (88lbs+), Advanced
Specifications:
Area: 140cm2
Span: 348mm
Aspect Ratio: 8.7
______________________________________________________

Flying V 200
If you want to rock the show then this is the tail for you!
The Flying V 200, is our take on what a radical tail wing should be! Inspired by our team rider, Skyrama’s own R&D, Armie has taken it further by mixing in some Americas Cup design secrets to create the very cutting edge Flying V…
Together with our radical test ripper, Beven Gooch, Armie has honed this design into a futuristic shape reminiscent of a heavy metal guitar! Its fast, loose and very carve-able, so you can take the lead on any wave! It extends the speed potential of any Armstrong front foil wing, making it ideal for rocking faster waves and head banging wingers!
The Flying V has been designed for the new A+System Fuselage. We’ve streamlined, strengthened and simplified the rear wing connection by attaching it directly to the A+System TC Fuselage and combining the current TTF shape directly into the fuselage. For most riders this means a simple direct shim-less connection of the tail wing. For more experienced riders our new Polycarbonate Pro Shims can easily be added to tailor your rig to your exact requirements and feel as you progress.
The Flying V is also compatible with original TC fuselage with the use of a TTF.
Construction
The tail wing has a foam core wrapped in the highest quality Carbon keeping it light and super rigid.
The Titanium screw inserts are in keeping with our philosophy of zero corrosion materials throughout the entire product range.
The unique flow fences improve stability by minimizing the disruption of turbulent flow from the front wing, mast and fuselage.
Dimensions
Tail Wing area: 200cm2 or Chop Shop 190cm2
Wingspan: 330 mm
Weight: 120 g
______________________________________________________

Flow 235
It’s all in the name.
The 235 Flow's name says it all! It’s smooth and predictable, inspiring your confidence and flow. Building on the much-loved HS232, this stabiliser adds a new section for consistent pitch stability, an increased projected aspect ratio and a refined planform to deliver an easy and free feeling ride. If you enjoy several foiling disciplines and want one stabiliser to cover them all, the Flow 235 is for you.

• Derived from the much-loved HS232 platform
• Developed in conjunction with the new MA foil range
• New section and thinner profile with more camber
• Higher projected aspect ratio for improved glide
• More responsive for pumping
• Consistent pitch stability

  Zippy Acceleration
  The foil section is thin but with pronounced camber, decreasing drag while also improving lift, forward projection and acceleration.
  Consistent Pitch
  Linear pitch characteristics throughout the full speed range even out front and back foot pressure, minimising lift spikes during acceleration and deceleration on the wave.
  Broader Speed Range
  A high camber section delivers the perfect blend of lift at low speeds to make getting onto foil easy, yet retains excellent controllability at high speeds.

Specifications:
Area: 235cm2
Span: 386mm
Aspect Ratio: 6.4
__________________________________________________

Surf 205
Fast and responsive to unleash your inner shredder.
The 205 Surf is a highly manoeuvrable stabiliser that enables tight and critical turns in the pocket. This design is derived from the low aspect HS212 (chopped HS232) which dedicated surf foilers found to be the ticket for foil surfing. The 205 builds on that with refinements to the foil section, planform and thickness to unlock the most freedom on the wave.

• Derived from the HS212 (chopped 232)
• Developed in conjunction with the new MA foil range
• New section and thinner profile with more camber
• Lower aspect for surfing in the pocket
• Consistent pitch stability



Zippy Acceleration

The foil section is thin but with pronounced camber, decreasing drag while also improving lift, forward projection and acceleration.

Consistent Pitch

Linear pitch characteristics throughout the full speed range even out front and back foot pressure, minimising lift spikes during acceleration and deceleration on the wave.

Broader Speed Range

A high camber section delivers the perfect blend of lift at low speeds to make getting onto foil easy, yet retains excellent controllability at high speeds.
Specifications:
Area: 205cm2
Span: 344mm
Aspect Ratio: 5.9
